Enhanced control of a two-wheeled gyroscopic combat robot with variable CMG disk speeds using LQR-Based neural network

This study proposes a hybrid control approach to improve the stability and adaptability of a two-wheeled gyroscopic combat robot by integrating deep learning with Linear Quadratic Regulator (LQR) control. Due to their inherently unstable nature, two-wheeled robots face challenges maintaining balance, especially when Control Moment Gyroscope (CMG) disk speeds vary, which significantly affect system dynamics. While LQR provides effective stabilization by minimizing a cost function, its performance degrades when disk speeds change. To overcome this limitation, a Neural Network (NN) was trained on 42001 precomputed LQR gain sets optimized for CMG disk speeds ranging from 800 to 5000 rad/s. The trained NN predicts appropriate coefficients in real time, enabling adaptive control under dynamic operating conditions. Simulation results demonstrate that the hybrid NN-LQR controller maintains stability under recoil forces up to 3000 N, where the conventional LQR loses balance about 4–6 seconds. Furthermore, the proposed controller reduces energy consumption by 21.6% during steady-state operation within the first 5 seconds and 10.6% under recoil conditions within the first 3 seconds compared to classical LQR. Although developed for a combat robot, the proposed framework offers a scalable solution for broader robotic applications such as search and rescue, surveillance, and autonomous navigation in complex environments, contributing to the advancement of intelligent control in robotics.
